Nitrogen Tanks
The use of liquid nitrogen for the storage of biological samples should be done with caution. This popular coolant boils quickly when it touches surfaces that are hotter (or less cold), which decreases the efficiency of the procedure. Additionally, when a substance boils at temperatures below the freezing point of water, an effect occurs where an insulating cover of nitrogen bubbles forms on the cooled object, known as the Leidenfrost effect.
This effect can be partially compensated by immersing objects in a mixture of solid and liquid nitrogen, rather than just the element in its liquid form, thus achieving faster cooling. It should not be neglected, that people who handle liquid nitrogen should do with all precautions and safety standards to avoid any accident.
Types of Nitrogen Tanks a Laboratory May Need
Small Sizes Storege- Smart Liquid Nitrogen Containers
- Low LN2 Consumption and Maximum Storage Efficiency:
Haier Biomedical’s Small Sized Storage Series (Square Racks) Liquid Nitrogen Storage System features low LN2 consumption and small storage capacity for laboratory applications. The lightweight containers have a smaller footprint whilst providing maximum efficiency of cryogenic storage capacity. - Advanced Vacuum Technology and Super-insulation Technology
Advanced vacuum and insulation technologies provide ultra-low liquid nitrogen evapouration loss and ensure up to three months cryogenic storage.
Medium Sizes Storege- Smart Liquid Nitrogen Containers
- ULT Storage with Extremely Low LN Evapouration Loss
Freezer racks are in the ultra-low temperature environment with extremely low LN2 evapouration. Even stored in vapour phase, the temperature will be below -190°C for a long time.
- Advanced Vacuum Technologyand Superinsulation Technology
Advanced vacuum and insulation technologies ensure cryopreser-vation for up to four months - Compatible for Blood Bag Storage
Suitable for blood bag applications, the racks can be adapted to provide temporary blood bag storage before transferring bags to larger LN2 storage tanks.
At Kalstein you can find the ideal Nitrogen Tanks for your Laboratory
Biomedical Liquid Nitrogen Storage Solutions Dryshipper Series for Transportation
Dryshipper Series for Transportation (Round Canisters) is designed for safe sample transportation under ...
Biomedical Liquid Nitrogen Storage Solutions YR05423 // YR05437
Liquid Nitrogen Supplement Series for LN2 Storage and Supply incorporates the latest innovation, its unique design...
High Capacity Series for Storage or Transport (Round Canisters) YR05383 // YR05392
Narrow neck design and excellent thermal conduc-tivity reduces evapouration loss of liquid nitrogen to extend storage times...
Small Sized Storage Series (Square Racks) YR05371 // YR05382
Widely used within many laboratories, this small-sized storage series features low LN₂ consumption and dual handle...
Our Top Selling Nitrogen Tank
- Durable Aluminum Construction
- Compatible with All Major Cryogenic Box Brands
- Large Opening Diameter and Large Capacity
- Ultra-Low Evaporation Loss
- 65 Litre to 175 Litre Capacity
- 5 Year Vacuum Warranty
Medium Sized Storage Series (Square Racks) features low LN2 consumption and relatively small footprint for medium capacity sample storage.
- ULT Storage with Extremely Low LN2 Evapouration Loss
- Advanced Vacuum Technology and Superinsulation Technology
- Compatible for Blood Bag Storage
| Model | YR053296-7 | YR053296-8 | YR053296-9 | YR053297 | YR053298 | YR053299 |
| Maximum Storage Volume | ||||||
| 2ml Storage Vials (100/box) | 4800 | 6000 | ||||
| Layers in Rack | 8 | 10 | ||||
| 5ml Storage Vials (81/box) | 1944 | 2430 | ||||
| Layers in Rack | 4 | 5 | ||||
| Function | ||||||
| Liquid Nitrogen Volume (L) | 145 | 175 | ||||
| Static Evapouration Rate* (%/d) | 0.94 | 0.94 | ||||
| Static Holding Time** (Day) | 154 | 186 | ||||
| Dimensions | ||||||
| Neck Opening (mm) | 216 | 216 | 216 | |||
| Overall Height (mm) | 946 | 1060 | 1060 | |||
| Overall Diameter (mm) | 681 | 681 | 681 | |||
| Empty Weight (kg) | 49.9 | 48.9 | 54.8 | 53.8 | ||
| Full Weight (kg) | 158.9 | 157.3 | 199.5 | 198.5 | ||
| Shipping Weight (kg) | 82.1 | 80.1 | 91.3 | 89.2 | ||
| Aditional Features | Includes 6 racks for 5ml, 4 layers in total, 24pcs of 5ml 9*9 cryo boxes and lockable cap included, no PU bag, roller base is optional |
Includes 6 racks (8 layers), 9*9 cryoboxes, lockable cap, no protective jacket, roller base is optional |
Includes lockable cap, no rack, no protective jacket |
Includes 6 racks for 5ml, 5 layers in total, 30pcs of 5ml 9*9 cryo boxes and lockable cap included, no protective jacket, roller base is optional |
Includes 6 racks (10 layers), 9*9 cryoboxes, lockable cap, no protective jacket, roller base is optional |
Includes lockable cap, no rack, no protectiv |
